Contact Rating: 5A 125VAC 3A 250VAC or 1A@24VDC ;
Electrical Life: 1,000,000 cycles
Contact Resistance: 50mΩ max.
Insulation Resistance: 100MΩ min.
Withstand Voltage: 1000VAC for 1 min
???????
介紹：
急停按鈕開關YG系列,產品按鈕有圓形18mm、正方形18*18mm、矩形18*24mm，指示燈，帶燈按鈕，旋鈕，鑰匙鈕，急停鈕，蜂鳴器等多種規格，產品性能穩定，接觸電阻小，耐振動耐沖性強，常用于電梯、機械設備、起重設備等。
Contact Rating: 5A 125VAC 3A 250VAC or 1A@24VDC ;
Electrical Life: 1,000,000 cycles
Contact Resistance: 50mΩ max.
Insulation Resistance: 100MΩ min.
Withstand Voltage: 1000VAC for 1 min
???????
